Properties:
NOMEX Filter Bags is popular in Asphalt mixing plant , water repellent treatment .Nomex filter bag offer one of the best total economies in a filtration system because of higher air to cloth ratios, higher temperature resistant function ,and long wearing life .
Send us email
filter@xinlifilters.comCall us
+86-15836052206NOMEX Filter Bags is popular in Asphalt mixing plant , water repellent treatment .Nomex filter bag offer one of the best total economies in a filtration system because of higher air to cloth ratios, higher temperature resistant function ,and long wearing life .
1) Performs at high temperatures
It is used in continuously operating temperatures up to 218°C (425°F) , and Nomex filter bags can handle higher temperature surges.
2) Resists flexing and abrasion
Flex and abrasion resistance function of Nomex filter bag at ambient temperature is good.
3) Good retardant function of moisture
Nomex filter bag performs well at high operating temperatures with normal amounts of moisture. The wear life projections in the below graphs were developed using 6-10% H20.
4) Dimensional Stability
Nomex filter bag , aramid filter bag is one of the most dimensionally stable dust filter bags available. Fibers of Nomex properly manufactured and finished, should neither stretch nor shrink over 2% when operated at temperatures up to 218°C (425°F).
5) High temperatures resistant
The most effective use of Nomex filter bag , aramid filter bag is in high efficiency filtering systems where effluent temperatures are above 250°F or in systems with surges over 250°F. In hot gas filtration systems.
| Material (mesh opening) | Nomex needle felt |
| Mesh count | 14-12000 mesh |
| Mesh opening | 1-14000 micron |
| Filter bag size |
1: Φ180x430mm(Φ7x17inch) 2: Φ180x820mm (Φ7x32inch) 11: Φ230x430mm (Φ9x17inch) 12: Φ230x820mm (Φ9x32inch) |
| Type | mesh filter bag, pocket filter, filter elements |
| Shapes | Seaming, seam with steel ring, hot melt with plastic ring or customized |
| Usage | liquid filter, dust filter, air filter |
